| Product Name: | Melthene-M
|
| Generic Name: | Adhesive Polymer
|
| Chemical Formula / Diagram: | N/A |
| Product Overview: | Melthene-M offers excellent adhesion with most substrates, without the use of solvents.
|
| Applications: | Easy-to-peel seals - Plastic containers for food and other goods.
|
|
Typical Properties/Grades:
| | TEST METHOD | UNIT | MX02 | MX06 | MX07 | MX10 | MX11 | MX23 | MX31 |
| MELT FLOW RATE | JIS K-6924-1 | g/10 min. | 9 | 46 | 32 | 15 | 7.5 | 90 | 9 |
| DENSITY | JIS K-6924-2
| g/cm3 | 0.93 | 0.95 | 0.94 | 0.94 | 0.95 | 0.96 | 0.93 |
| TENSILE STRENGTH | JIS K-6924-2
| kgf/cm2 | 135 | 90 | 95 | 100 | 130 | 70 | 190 |
| ELONGATION | JIS K-6924-2
| % | 740 | 790 | 780 | 570 | 790 | 920 | 880 |
| HARDWARE (SHORE A) | JIS K-7215
| | 88 | 84 | 85 | 96 | 92 | 91 | 96 |
| VICAT SOFTENING TEMPERATURE | JIS K-7206
| ºC | 69 | 48 | 49 | 71 | 55 | 50 | 70 |
| MELTING POINT | DSC | ºC | 97 | 83 | 84 | 118 | 127 | 83 | 122 |
| | |
| Product Name: | Melthene-H
|
| Generic Name: | Adhesive Polymer
|
| Chemical Formula / Diagram: | N/A |
| Product Overview: | Melthene-H is a saponified ethylene vinyl acetate copolymer, having weather resistance, solvent resistance and excellent adhesion to various substrates.
|
| Applications: | Extrusion coating - Textile, lumber, plastic, rubber, metal, formed products, paper, packing film, etc.
|
|
TYPICAL PROPERTIES/GRADES:
| | TEST METHOD | UNIT | h6410m | h6051 | k502C | s102c | 900b (Black) | 900W (White) |
| MELT FLOW RATE | JIS K-6730 | g/10 min. | 16 | 5 | 115 | 220 | 30 | 28 |
| DENSITY | ASTM D1505 | g/cm3 | 0.95 | 0.97 | 0.96 | 0.96 | 1.07 | 1.10 |
| TENSILE STRENGTH | JIS K-6730
| kgf/cm2 | 120 | 170 | 110 | 110 | 160 | 180 |
| ELONGATION | JIS K-6730
| % | 730 | 500 | 570 | 580 | 410 | 400 |
| HARDness | JIS K-6760
| HDD | 38 | 70 | 53 | 53 | 66 | 67 |
| VICAT SOFTENING TEMPERATURE | JIS K-6730
| ºC | 54 | 100 | 73 | 71 | 90 | 90 |
| MELTING POINT | DSC | ºC | 87 | 110 | 104 | 100 | 113 | 113 |
| Application | Coextrusion
Excellent adhesion to metal
Modified Wire & Cable | Fusible interlining for clothes (Powder) | Powder coating |
| | | | |
| | |
| Product Name: | Melthene-G
|
| Generic Name: | Adhesive Polymer |
| Chemical Formula / Diagram: | N/A |
| Product Overview: | Melthene-G is a modified EVA for use as an adhesive for lamination. It excels in its adhesive properties to a wide variety of materials and easy processing ability.
|
| Applications: | Laminating - Textile, lumber, plastic, rubber, metal, formed products, paper, packing film, etc.
|
|
TYPICAL PROPERTIES/GRADES:
| | TEST METHOD | UNIT | Value |
| MELT FLOW RATE | JIS K-6730 | g/10 min. | 9.0 |
| DENSITY | ASTM D1505 | g/cm3 | 0.962 |
| TENSILE STRENGTH | JIS K-7113
| kg/cm2 | 190 |
| ELONGATION at break | JIS K-7113
| % | 850 |
| Flexible Modulus | JIS K-6730 | kg/cm2 | 85 |
| Dulometer A Hardness | JIS K-7215 | HAD | 89 |
| Dulometer D Hardness | JIS K-7215
| HDD | 36 |
| Vicat Softening Point | JIS K-6730
| ºC
| 48 |
Melting Point
| DSC Method | ºC
| 72 |
| Dielectric Constant 50Hz | JIS K-6911 | - | 3.46 |
| 1 KHz | JIS K-6911
| - | 3.41 |
| 1 MHz | JIS K-6911
| - | 2.98 |
| >Dielectric Dissipation Factor 50Hz | JIS K-6911
| - | 4.1x10-3 |
| 1 KHz | JIS K-6911
| - | 9.3x10-3 |
| 1 MHz | JIS K-6911
| - | 5.9x10-2 |
| | | | |
